Product Families / JUNIOR / press 3-point lock

JUNIOR
press 3-point lock
Article No
F9420-000022(BLK)
Sector
children, transportation, outdoor
Webbing width
25 mm
Weight
ca. 57 g
Material
PA66GF30, PA66GF15, POM
Static breaking load N
392 N
Static breaking load KG
40 kg
Colour
black, grey
Opening mechanisms
double press
Assembly
strap, single bar
Order Samples
DESCRIPTION

The JUNIOR press 3-point lock is one of our newest approaches to facilitating everyday childcare tasks and creating a reliable, quick, easy-to-use fastener for 3-point strap systems. This 3-point lock combines the comfort of intuitive single-handed opening with single-action safety requirements: The button of the fastener is pressed down in a pinching motion, which then releases the straps. The resistance of the button prevents accidental opening by toddlers. When being closed, the components of the JUNIOR press will automatically lock into place.

APPLICATION AREAS

The 3-point lock is, among others, suitable for prams, strollers, children seats on bicycles and cargo bikes. The buckle was developed with following standards in mind:

Din EN 15918 bicycle trailer

DIN EN 79010 cargo bikes

DIN EN 14344 children’s seats for bicycles

DIN EN 1888 Strollers

ASTM F833_15 Carriages and strollers

ASTM F1625-00 Rear-Mounted Bicycle Child Carriers

Testing after these standards is always specific to the application and must be accordingly done on the ready product before market launch.

FITTING

The JUNIOR press 3-point lock is simply attached to three 25 mm straps.


Not for use on child car seats.

Use for safety-related applications only after successful suitability testing by the manufacturer.

CUSTOMIZATION

The JUNIOR press 3-point lock is available with a printed logo. Custom colours and customized with a logo insert can also be requested.
