The JUNIOR press 5-point loop is one of our newest approaches to facilitating everyday childcare tasks and creating a reliable, quick, easy-to-use fastener for 5-point strap systems. This 5-point lock combines the comfort of intuitive single-handed opening with single-action safety requirements: The button of the fastener is pressed down in a pinching motion, which then releases the straps. The resistance of the button prevents accidental opening by toddlers. When being closed, the components of the JUNIOR press double will automatically lock into place. The fastener is used with three straps. However, to create a 5-point attachment, the shoulder/waist straps are looped through the 5-point lock.
The 5-point lock is, among others, suitable for prams, strollers, children seats on bicycles and cargo bikes. The buckle was developed with following standards in mind:
Din EN 15918 bicycle trailer
DIN EN 79010 cargo bikes
DIN EN 14344 children’s seats for bicycles
DIN EN 1888 Strollers
ASTM F833_15 Carriages and strollers
ASTM F1625-00 Rear-Mounted Bicycle Child Carriers
Testing after these standards is always specific to the application and must be accordingly done on the ready product before market launch.
The JUNIOR press 5-point loop is attached to products with three 25 mm wide straps. The shoulder/waist straps are looped through the fastener to create the 5-point functionality.
Not for use on child car seats.
Use for safety-related applications only after successful suitability testing by the manufacturer.
The JUNIOR press 5-point loop is available with a printed logo. Custom colours and customized with a logo insert can also be requested.
